Dual Spindle Automatic Winding Machine

The Dual Spindle Automatic Winding Machine is an efficient and precise fully automated device designed for high-volume production. It can wind two coils simultaneously, significantly improving production efficiency, and is ideal for industries such as electronics, automotive, and telecommunications.

This machine features advanced automation and control systems, making it an upgrade to the Fully Automatic Winding Machine and Fully Automatic Coil Winding Machine. With the dual spindle design, the Automatic Winding Machine can produce more coils per cycle, meeting the demands of high-speed, high-precision production.

Product Parameters:

Key Features of the Dual Spindle Automatic Winding Machine

Dual Spindle Design – Allows simultaneous winding of two coils, doubling production output and reducing processing time.

Fully Automated Operation – The system performs automatic wire winding, cutting, and stopping, reducing manual intervention and ensuring consistent quality.

High Precision Winding – With ±0.05mm precision, the machine maintains tight control over wire tension and layer count, ensuring uniformity.

Intelligent Control System – Equipped with a PLC control system and touchscreen interface, allowing easy adjustment of parameters and real-time monitoring of production status.

High-Speed Production – Capable of winding at speeds up to 1200 RPM, meeting high-volume production demands with outstanding efficiency.

Versatile Wire Compatibility – Supports copper wire, aluminum wire, and tinned wire, catering to diverse production needs.

Wide Application Range – Ideal for manufacturing inductors, transformers, common mode chokes, and other electrical components.

Applications of the Dual Spindle Automatic Winding Machine

Electronics Industry – Essential for producing inductors, transformers, and filters used in electronic circuits.

Automotive Industry – Used in the production of motor coils, sensors, and ignition components for automotive electronics.

Telecommunications Industry – Ideal for manufacturing common mode chokes and filter coils in communication devices.

Home Appliances – Used for winding electric motor coils, transformers, and other electrical components in household appliances.

Why Choose Our Dual Spindle Automatic Winding Machine?

Enhanced Productivity – With dual spindles, output is effectively doubled compared to single-spindle machines.

Reliable and Consistent Quality – High-precision control ensures each coil meets strict specifications.

User-Friendly Operation – The intuitive PLC touchscreen makes setup and operation simple and efficient.

Versatile & Scalable – Supports a wide range of wire types and coil sizes for varied production needs.

Reduced Labor Costs – Fully automated processes minimize manual work, improving efficiency.
